H3C UniServer R4900 G6 8SFF Silver 4509Y

CPU

2×4th Generation Intel®Xeon®Sapphire Rapids / 5th Generation Intel®Xeon®Emerald Rapids SP series

64 Cores for each Processor and 385W power consumption

HBM technology

Chipset

Inte®C741

Memory

32 DDR5 RDIMM Slots, 5600 MT/s Data Rate, 8TB* on 2 CPU Configuration

Additional 16 Expansion Memory Slots via CXL1*

Raid Controller

Dedicated PCIe HBA Controller or Raid Controller

Standard PCIe HBA Controller or Raid Controller

FBWC

8 GB Cache, support Supercapacitor Protection

Storage

29 SAS/SATA Drives

Front 12 LFF bays, Rear 4 LFF bays

Front 25 SFF bays, Rear 4 SFF bays

24 U.2 NVMe Drives

SATA/NVMe M.2 Kit, DSD Model (2×SD card kit)

Network

1 Onboard 1Gbps Management Network Port

2 Onboard OCP 3.0 Slots for 4 GE or 2 10GE or 2 25GE or 2 100GE NICs

PCIe Standard Slots for 1/10/25/100/200GE Ethernet Adapter, PRP NIC*

Expansion Slots

10 PCIe Standard Slots (6 PCIe5.0 and 4 PCIe4.0) and 2 Onboard OCP 3.0 Slots; CXL1.1

Supports Full-OCP architecture and can support up to 8 OCP3.0 slots*

Ports

Standard: 1 Rear VGA Port, 3 USB 3.0 Ports (1 Front, 2 Rear), 1 USB 2.0 Internal Port, 1 RJ45 Management Port

Optional: 1 Rear Serial Port, Mounting Bracket Kit with 1 Type-C Port, 1 VGA Port, 1 USB 2.0 Port

GPU

4 Dual-Slot* or 8 Single-Slot GPU Modules

Optical Drive

External Optical Disk Drive, Optional

Management

H3C HDM Standard License, iFIST (embedded), H3C Advanced Feature Package License (optional, requires licenses), H3C UniSystem (requires download)

Support LCD Touchable Intelligent Management Module

Security

Intelligent Front Security Bezel

Chassis Intrusion Detection

TPM 2.0

2FA for HDM

Intel SGX2.0

Power supply

1+1 Redundancy Power Supply

Titanium 1600W/3200W

Platinum 800W/1300W/1600W/2000W/2400W/2700W

DC Power Supply

Hot Swappable Redundant Fans

Standards

CE, UL, FCC, VCCI, CB, etc.

Operating Temperature

5°C to 45°C (41°F to 113°F)

Dimensions

(H×W×D)

2U Height

87.5×445.4×780mm (3.44×17.54×30.7 in) (Without a security bezel)

87.5×445.4×808mm (3.44×17.54×31.8 in) (With a security bezel)
